UPC# : 6733249649189
Prime Moving Head 12W RGB Laser , 10W RGB Laser & 6W RGB Laser Available Models.
Elevate Your Lighting Game with Illusion Universe.
Step into the future of lighting with the Prime Moving Head 12W RGB Laser—a cutting-edge masterpiece from Illusion Universe. Designed for professionals who demand precision, performance, and stunning visual impact, this powerful laser delivers unmatched clarity and dynamic effects to transform any venue. Whether you’re running a club, theater, or live event, the Prime Moving Head RGB Laser is your ultimate partner in creating unforgettable moments.
Features
-
High-speed 40kpps scanning system for ultra-smooth animations and sharp beam effects
-
16-bit precision movement for accurate and dynamic positioning
-
Analog RGB modulation for vibrant, consistent, and true-to-life colors
-
Multiple control options: DMX512 (6/40 channels), ILDA, SD Card, Auto, Sound-Activated, Master-Slave
-
3-pin DMX & 25-pin ILDA connectivity for professional integration
-
RDM bidirectional communication for advanced fixture management
-
Automatic error correction & reset function for reliable performance
-
Built-in temperature control system for enhanced durability and diode life
-
Supports custom patterns, animations, logos, and beam effects
-
Effects include strobe, rotation, zoom, movement, blanking, and speed control
-
SD card support for easy playback and upgrades
-
Upgradeable via DMX & SD card for future enhancements
-
Designed for professional use in clubs, concerts, theaters, and large events
Prime Moving Head 12 Watt Laser RGB Illusion Universe
Technical Specifications
-
Power & Operation
-
Voltage: AC100-230V, 50/60Hz
-
Power Consumption: 250W max
-
Scan System
-
Speed: 40kpps
-
Maximum Scan Angle: ±30°
-
Horizontal Scan Range: 540° (16-bit precision)
-
Vertical Scan Range: 270° (16-bit precision)
-
Reset Function: Automatic error correction
-
Laser Modulation & Beam Specs
-
Modulation Type: Analog
-
Laser Beam Diameters:
-
12W/10W: 6 x 6.5mm
-
6W: 3 x 6.5mm
-
Beam Divergence: < 1.2mrad
-
Control Modes
-
DMX512 Channels: 6/40
-
Other Modes: Auto, Sound-Activated, Master-Slave, ILDA, SD Card
-
Control Interfaces
-
DMX Connector: 3-pin DMX512
-
ILDA Connector: 25-pin DB
-
Expansion: SD Card Slot
-
Advanced Control Features
-
RDM Data Transmission: Enables bidirectional communication.
-
Temperature Control System: Maintains optimal performance and diode longevity.
-
DMX512 Upgrade Capability
-
SD Card Upgrade Functionality
-
DMX Lighting Effects
-
Patterns: Blanking, strobe, rotation, movement, zoom, and more
-
Color & Speed Effects: Fully customizable
-
Operating Environment
-
Temperature Range: 0°C to 35°C
-
Conditions: Dry, low-dust
-
Physical Specifications
-
Single Unit Packaging:
-
Dimensions: 52 x 41 x 70 cm
-
Weight: 23.5 kg
-
2-in-1 Flight Case:
-
Dimensions: 83 x 54 x 79 cm
-
Weight: 77 kg
-
Certification:
-
CSA Special Publication SPE-1000-21 Write the above line in caps
Why Choose the Prime Moving Head RGB Laser?
-
Next-Level Animation & Beam Effects: With high-speed 40kpps scanners and ultra-precise 16-bit movement, your visuals will shine with smooth, detailed animations and eye-popping beam shows.
-
Ultimate Control at Your Fingertips: Featuring DMX512 (6/40 channels), ILDA, SD card, sound activation, and more, this laser lets you control every nuance of your lighting design.
-
Razor-Sharp RGB Colors: Analog modulation ensures vibrant, consistent colors for animations, patterns, and custom logos.
-
Built for Reliability: Equipped with RDM bidirectional communication, automatic error correction, and temperature control, the Prime Moving Head ensures stable, long-lasting performance
Applications
Turn ordinary venues into extraordinary experiences. Perfect for:
-
Discos & Clubs: Electrify the dance floor with jaw-dropping visuals.
-
Theaters: Create dramatic lighting effects that captivate every seat.
-
Events & Concerts: Wow audiences with custom laser animations and beam shows.
• Indoor Venues: Optimize for medium-sized spaces with tailored light outputs.
Transform Your Space Today!
The Prime Moving Head 12W RGB Laser is more than just a lighting fixture—it’s an experience. Its vibrant RGB colors, dynamic effects, and advanced control systems make it the ideal solution for lighting professionals who need precision and power.
Call to Action
Ready to Transform Your Event?
Experience the brilliance of the PRIME SERIES and elevate your productions to the next level.
Contact Us today to learn more or fill the form below.
