TORNADO FLAMER SF-180

The TORNADO FLAMER SF-180 is a professional stage flame effect machine designed to create powerful, dynamic fire effects for live performances, concerts, festivals, and large-scale events. Featuring a flame height of up to 10 metres and a 210° rotating nozzle, it produces sweeping flame effects that add intensity and visual impact to stage productions. Its 10-litre fuel tank and ISOPAR liquid fuel system make it suitable for demanding live entertainment applications.


Designed for controlled and synchronised flame effects, the TORNADO FLAMER SF-180 features DMX512 control, 89 DMX effects, fast electronic ignition, and compatibility with professional show-control platforms such as Finale 3D, Depence, MA2, and MA3. Its dual-valve and pump safety system, adjustable nozzle, and IPX3-rated water protection make it a versatile solution for professional stage productions when operated under appropriate safety procedures.

Features

Features

  • 10-Metre Flame Height: Creates dramatic flame effects for large stages and live events.

  • 210° Rotating Flame: Adjustable nozzle movement from -105° to +105° for sweeping fire effects.

  • 89 DMX Effects: Supports a variety of programmed flame sequences.

  • Dual-Valve & Pump Safety: Integrated safety system for controlled operation.

  • IPX3 Water Protection: Designed to provide protection against water spray under specified test conditions.

  • 10-Litre Fuel Tank: Provides onboard fuel storage for performances.

  • ISOPAR Liquid Fuel: Designed for use with the specified ISOPAR fuel.

  • Fast Electronic Ignition: Supports rapid ignition response for synchronised effects.

  • Interchangeable Nozzles: Different nozzles can produce flame heights ranging from 3 to 10 metres and different flame shapes, according to the supplied product information.

  • DMX512 Control: Enables integration into professional lighting and show-control systems.

  • Show-Control Compatibility: Compatible with Finale 3D, Depence, MA2, and MA3, as specified by the manufacturer.

  • Instagram
  • Facebook
  • YouTube
  • TikTok

What are the Technical Specifications of TORNADO FLAMER SF-180?

  • Product Name: TORNADO FLAMER SF-180

  • Product Type: Flame FX

  • Maximum Flame Height: Up to 10 m

  • Flame Height Range: 3–10 m, depending on nozzle

  • Flame Rotation / Effect Angle: 210°

  • Nozzle Adjustment: -105° to +105°

  • Built-in DMX Effects: 89

  • Input Voltage: AC 200–240 V, 50 Hz / AC 100–120 V, 60 Hz

  • Power Consumption: 320 W

  • Power Connector: Neutrik® powerCON TRUE1 (in & out)

  • Control Options: DMX; 15–24 V–24 V firework ignition signal interface, as specified in the supplied information

  • Control Protocol: DMX512

  • Control Connectors: Neutrik® 3-pole male/female XLR

  • Consumable / Fuel: ISOPAR liquid fuel

  • Fuel Consumption: 3.6 L/min

  • Fuel Tank Capacity: 10 L

  • Safety System: Dual-valve and pump safety

  • Ignition: Electronic ignition

  • Water Protection Rating: IPX3

  • Compatible Software: Finale 3D, Depence, MA2, MA3

  • Dimensions (L × W × H): 630 × 363 × 373 mm

  • Net Weight: 32 kg

  • Package Dimensions (L × W × H): 870 × 440 × 620 mm

  • Packaged Weight: 51 kg

Gallery
Ts
Applications

Applications

​

  • Concerts and Live Events: Create dramatic flame effects and synchronised fire sequences for live performances and music shows.

  • Festivals and Outdoor Productions: Enhance large-scale entertainment events with sweeping flame effects, subject to venue and weather safety requirements.

  • Theatre and Stage Productions: Add controlled fire effects to theatrical performances, stage shows, and special productions.

  • Nightclubs and Entertainment Venues: Create high-impact visual moments for professionally managed entertainment shows.

  • Theme Parks and Special Effects Shows: Integrate flame effects into choreographed attractions and live spectacle productions.

  • Event Production and Show Control: Synchronise flame effects with lighting and time-coded sequences through compatible control systems.

​Frequently Asked Questions (FAQs)


1. What is the maximum flame height of the TORNADO FLAMER SF-180?

The TORNADO FLAMER SF-180 can produce flames up to 10 metres high. The actual height depends on the nozzle configuration and operating conditions.


2. What type of fuel does the TORNADO FLAMER SF-180 use?

The machine is specified for ISOPAR liquid fuel. Always use only the manufacturer-approved fuel grade and follow the prescribed handling and operating instructions.


3. Can the TORNADO FLAMER SF-180 be controlled through DMX?

Yes. It supports the DMX512 control protocol and offers 89 listed DMX effects for integration into compatible show-control systems.


4. What is the rotation angle of the TORNADO FLAMER SF-180?

The nozzle provides a 210° effect angle, with an adjustable range from -105° to +105°, enabling sweeping flame effects.


5. Is the TORNADO FLAMER SF-180 suitable for outdoor events?

It has an IPX3 water-protection rating, but this does not make it fully waterproof. Outdoor use must comply with the manufacturer's environmental restrictions, venue regulations, fire-safety requirements, and applicable operating clearances.
