HYDREX WASHFLOW FX1650 IP

16×50W Outdoor Hybrid FX Wash Moving Head


The HYDREX WASHFLOW FX1650 IP is a high-performance outdoor LED moving wash fixture engineered for professional touring, festivals, and permanent installations.

​

Featuring a dual-layer lighting system with 16×50W RGBL main LEDs and integrated auxiliary FX LEDs, this fixture delivers powerful wash output, pixel-mapped effects, and immersive aura visuals in a single robust unit.

​

Built with IP66 protection, fast movement, and precision optics, it ensures reliability in harsh environments while maintaining premium visual performance.

​

Designed for creative lighting professionals, the FX1650 IP unlocks limitless design possibilities with advanced pixel control and dynamic effect layering. From sharp, focused beams to expansive washes and ambient aura effects, it seamlessly adapts to diverse stage and architectural lighting requirements.

​

Its robust construction combined with intelligent control protocols makes it an ideal solution for large-scale productions and demanding outdoor environments. Whether used for concerts, live events, or permanent installations, the fixture delivers consistent performance, stunning visual impact, and long-term operational reliability.

Technical Specifications

• Electrical

• Input Voltage: AC 100–240V, 50/60Hz

• Power Consumption: 900W

• Power Factor: ≥0.95

• Power Connection: Waterproof PowerCON In/Out


• Light Source

• Main LEDs: 16 × 50W High-Power RGBL LEDs

• Auxiliary LEDs: 0.3W 5050 RGB LEDs (Aura/Background Effect)

• LED Life Expectancy: ≥50,000 hours

• Color Temperature: Variable (RGBL Mixing)

• CRI: ≥85


• Optical System

• Zoom Range: 4° – 60° Linear Motorized Zoom

• Beam Angle: Narrow Beam to Wide Wash

• Color Mixing: Advanced RGBL Uniform Mixing System

• Lens Type: High-efficiency optical lenses

• Output: High-intensity, even field projection


• Effects & Features

• Pixel Control: Individual LED pixel mapping

• Built-in Effects:

• Rainbow

• Chase

• Flow

• Wave

• Aura Effect: Inner aperture dynamic color effects

• Strobe: 1–30 Hz variable speed

• Dimmer: 0–100% smooth linear dimming

• Dimming Curves: Linear, exponential, logarithmic, S-curve

• Color Effects: Virtual color wheel + macros


• Movement

• Pan: 540° (16-bit resolution)

• Tilt: 270° (16-bit resolution)

• Movement Speed: Fast and smooth positioning

• Pan/Tilt Correction: Auto repositioning

• Motor Type: High-precision 3-phase motors

• Control System

• DMX Channel Modes:

• Basic: 24 CH

• Standard: 44 CH

• Extended: 48 CH / 113 CH

• Control Protocols: DMX512, RDM, Art-Net

• Display: OLED Touch Screen Display

• Firmware Upgrade: Via DMX / USB / Network

• Control Modes: DMX, Master/Slave, Auto, Sound


• Connections

• DMX Input/Output: Waterproof 3-pin XLR

• Power Input/Output: Waterproof PowerCON

• Network: Waterproof RJ45 (Art-Net)

• Data Protection: IP-rated sealed connectors


• Construction & Build

• Housing Material: Die-cast aluminum

• Finish: Anti-corrosion coating

• Cooling System: Intelligent temperature-controlled cooling (fan + heat sink)

• Noise Level: Low-noise operation

• Protection Features:

• Overheat protection

• Overcurrent protection


• Physical Specifications

• IP Rating: IP65 (Outdoor Rated)

• Dimensions: 392 × 283 × 511 mm

• Weight: 21 kg

• Mounting: Omega brackets / truss mounting compatibility

• Orientation: Any working position


• Environmental

• Operating Temperature: -20°C to +45°C

• Storage Temperature: -25°C to +60°C

• Humidity: Up to 95% non-condensing


• CERTIFICATIONS & SAFETY

• Evaluated to m SPE-1000 for Canadian installation. U.S. field evaluation available upon request. Designed to comply with applicable CE and RoHS requirements.
