FLUX BAT IP

Battery-Powered Wireless DMX IP65 LED PAR Light


The FLUX BAT IP from Illusion Universe is a professional battery-powered LED PAR light designed for flexible event lighting, stage productions and architectural illumination. Featuring 7 × 20W RGBL four-in-one LEDs, it delivers vibrant colour mixing and versatile lighting effects in a compact fixture. Its battery-powered design allows convenient placement in locations where power cables may be difficult to manage, making it suitable for creating clean, professional lighting setups.


Designed for event professionals, rental companies and lighting designers, the FLUX BAT IP combines wireless DMX control, support for DMX512/RDM as listed in the supplied reference, and an IP65-rated housing for suitable outdoor applications. With a standard 10° beam angle and optional 25° and 45° configurations, it offers flexibility for highlighting architectural features, enhancing wedding décor, illuminating stages and creating atmospheric effects at corporate events and exhibitions.

Features

Features

  • Battery-Powered Operation: Enables flexible fixture placement without requiring a continuous mains power connection during battery operation.

  • RGBL Colour Mixing: Equipped with 7 × 20W RGBL four-in-one LEDs for vibrant colours and versatile lighting effects.

  • Wireless DMX Control: Supports wireless DMX operation for convenient control and reduced signal-cable requirements.

  • DMX512 and RDM: Wired DMX512/RDM support is listed in the supplied product reference; confirm the final fixture configuration.

  • IP65 Outdoor Protection: Designed for suitable outdoor lighting applications with an IP65-rated housing.

  • Multiple Beam Angle Options: Features a standard 10° beam angle, with optional 25° and 45° configurations.

  • Multiple Battery Runtime Modes: Reference runtime figures vary by mode, output and colour selection.

  • Durable Aluminium Housing: Aluminium construction for professional event and installation environments.

  • Compact Fixture Design: Suitable for flexible placement in event spaces, venues and architectural lighting setups.

  • Professional Applications: Ideal for weddings, stages, exhibitions, corporate events, rental production and architectural accents.

  • Instagram
  • Facebook
  • YouTube
  • TikTok
Gallery

What are the Technical Specifications of FLUX BAT IP?

Ts

  • Brand: Illusion Universe

  • Model: FLUX BAT IP

  • LED source: 7 × 20 W RGBL four-in-one LEDs (LED rating: 140 W total)

  • Maximum power listed on reference flyer: Up to 70 W (7 × 20 W is also listed; confirm final power specification before publication)

  • Colour mixing: RGBL

  • Beam angle: 10° standard; 25° / 45° optional

  • Control: Wireless DMX; DMX512 / RDM listed on reference flyer

  • DMX channels: 6 / 10 channels

  • Ingress protection: IP65 outdoor-rated housing

  • Input voltage: 220 VAC listed on reference flyer; confirm accepted voltage and power input for your unit

  • Dimensions: 270 mm height × Ø160 mm

  • Weight: 4.5 kg per fixture

  • Housing: Aluminium; black matte, grey anodized or green listed

  • Operating temperature: 0°C to +55°C; optional upgrade to 70°C listed

  • Humidity: 0–80%, non-condensing

  • Fixture connectors: 3-pin or 5-pin XLR male/female DMX connectors listed

  • Warranty: 2 years; 3-year option listed in reference flyer

  • Battery Performance:

  • Boost Mode: 4 hours at full power; 20 hours in single-color mode.

  • Medium Mode: 6 hours at full power; 24 hours in single-color mode.

  • Eco Mode: 8 hours at full power; 32 hours in single-color mode.

Applications

​

The Confetti Cannon Plus SF-CC46 is suitable for a wide range of professional entertainment and celebration environments.


  • Weddings and Celebrations: Illuminate mandaps, floral arrangements, stage backdrops, reception décor and event features.

  • Stage and Live Events: Create colourful lighting effects for performance areas, stage designs and entertainment productions.

  • Architectural Lighting: Highlight columns, building façades, walls and selected architectural details.

  • Corporate Events and Exhibitions: Enhance exhibition booths, product displays, conference stages and branded environments.

  • Rental and AV Productions: Provide flexible lighting placement for temporary installations, event venues and production setups.

Applications
​Frequently Asked Questions (FAQs)


1. What is the FLUX BAT IP LED PAR light?

The FLUX BAT IP is a battery-powered wireless DMX LED PAR light featuring 7 × 20W RGBL LEDs, an IP65-rated housing and multiple beam angle options. It is designed for professional event, stage and architectural lighting.


2. Is the FLUX BAT IP suitable for outdoor use?

Yes, the supplied product reference specifies an IP65 rating for suitable outdoor applications. Always follow the manufacturer's instructions for outdoor operation and ensure connectors are properly sealed and protected.


3. How long does the FLUX BAT IP battery last?

The supplied reference lists up to 4 hours in Boost Mode, 6 hours in Medium Mode and 8 hours in Eco Mode at full power. Single-colour operation is listed at 20–32 hours, depending on the mode and operating conditions.


4. Does the FLUX BAT IP support wireless DMX control?

Yes, wireless DMX is a key feature. DMX512 and RDM are also listed in the supplied reference. Confirm compatibility with your lighting controller, transmitter and the specific fixture configuration before installation.


5. Which beam angles are available for the FLUX BAT IP?

The standard beam angle is listed as 10°, with optional 25° and 45° versions. The 10° option is suitable for more concentrated lighting, while wider angles can cover larger areas. Confirm the selected optic when ordering.
