The CL-C200F Rainproof Controller is a powerful and reliable control system designed for advanced pixel LED lighting applications. Built with an integrated power supply and a durable rainproof housing, this controller ensures stable performance even in challenging outdoor environments. It is ideal for architectural lighting, media facades, stage lighting installations, and decorative LED pixel systems.
Supporting multiple professional control protocols including ARTNET, sACN, and SD Card offline control, the CL-C200F provides flexible integration with modern lighting systems. With the capability to control up to 680 pixels on a single output port, the controller delivers high-performance data transmission and accurate lighting effects for complex installations.
Designed with ease of use in mind, the controller features simple wiring, built-in power supply, and support for effect recording. Users can store up to 31 lighting effects for offline playback, making it suitable for projects where a computer or console is not required during operation.
Features
-
Multiple Control Protocol Support: Supports ARTNET, sACN, and SD Card control modes, allowing seamless integration with professional lighting control systems.
-
High Pixel Control Capacity: The controller can control up to 680 pixels through a single output port, making it ideal for medium-scale pixel lighting installations.
-
Built-in Effect Recording: The system supports recording up to 31 lighting effects, enabling offline operation without external control software.
-
Built-in Power Supply: Integrated 200W power supply simplifies installation and reduces the need for additional equipment.
-
Offline Operation: With SD card mode, pre-programmed lighting effects can run automatically without connecting to a computer or lighting console.
-
Durable Rainproof Design: With an IP65 waterproof rating, the controller is designed to withstand dust, rain, and outdoor environmental conditions.
-
Easy Installation: The controller features simple wiring and compact design, allowing quick installation and maintenance.
Technical Specifications
-
Input Voltage: AC110–220V
-
Output Voltage: DC24V
-
Power: 200W
-
Control Modes: ART-NET / sACN / SD Card
-
Working Modes: ARTNET / SD Card
-
Output Ports: 1 Port
-
Maximum Pixel Control: 680 Pixels
-
Cascaded Units: Up to 254 Controllers
-
Effect Storage: 31 Built-in Effects
-
Product Dimensions: 170 × 90 × 50 mm
-
Gross Weight: 0.8 kg
-
Protection Rating: IP65 (Dust & Water Resistant)
Applications
The CL-C200F Rainproof Controller is suitable for a wide range of professional LED lighting installations, including:
-
Architectural façade lighting
-
Outdoor pixel LED installations
-
Media façade lighting systems
-
Stage and entertainment lighting setups
-
Theme parks and decorative lighting
-
Bridges, buildings, and landscape lighting
-
Commercial and public space illumination
Why Choose CL-C200F Rainproof Controller
✔ Reliable outdoor-ready IP65 design
✔ Supports multiple professional lighting protocols
✔ High pixel control capacity for complex lighting setups
✔ Offline playback capability with SD card support
✔ Built-in 200W power supply for simplified installation
✔ Compact and lightweight industrial-grade design
The CL-C200F controller offers a perfect balance of performance, reliability, and flexibility, making it an excellent solution for both permanent installations and temporary lighting projects
